Digital Hotplate LZ-DHP-A102
Digital Hotplate LZ-DHP-A102
www.labotronics.co.in info@labotronics.co.in
Digital Hotplate LZ-DHP-A102
Digital Hotplate LZ-DHP-A102 is a PID temperature controlled hotplate with convenient temperature setting via on-touch control. It offers 1500 W and 400 × 300 mm plate dimension. LED screen displays preset and current temperature value for visual monitoring of parameters. Built-in alarm signal output for stoppage of hotplate operation. External temperature control for direct and precise control of actual temperature.
Features :
- Designed with PID temperature control technology for accurate and reliable results
- Convenient temperature setting via on-touch control
- Offers complicated temperature control requirements
- Designed with bright LED screen can display both set value and actual temperature
- Material used aluminum coated with ceramic
- Timer function for automatic heating up to 100 hours
- Equipped with alarm signal output which can be applied to stop the operation of the hot plate and the other connected devices
- Offers external PT100 temperature sensor connection for direct and precise control of the actual temperature
Specifications :
| Display Mode | LED |
|---|---|
| Set Temperature Range ( top plate) | 50 to 300˚C |
| Plate Dimension | 400 × 300 mm |
| Power | 1500 W |
| Temperature Stability | ± 2˚C |
| Hot plate material | Aluminum coated with ceramic |
| Temperature Sensor | PT100-01 |
| Temperature Holder | PT100-05 holder |
| Set Temperature Range (with Pt100 sensor) | 40 to 300˚C |
| Outer Dimension | 470 × 410 × 70 mm |
| Packing Dimension | 700 × 650 × 250 mm |
| Net Weight | 7.0 kg |
| Gross Weight | 12.0 kg |
Applications :
Digital Hotplate is used to uniformly heat samples and to heat glassware in a laboratory setting.
